Duralox 92W - Micro Beads
Product Details:
- Color White
- Size Dia 0.4-0.7,0.7-1.2,1.2-1.7,1.7-2.4,2.4-2.8,2.8-3.3 (mm)
- Usage Shot Peening,De-burring & polishing
- Ceramic Type Ceramic Balls
- Material Alumina Ceramic
- Click to View more
Duralox 92W - Micro Beads Price And Quantity
- 25 Kilograms
Duralox 92W - Micro Beads Product Specifications
- Shot Peening,De-burring & polishing
- Dia 0.4-0.7,0.7-1.2,1.2-1.7,1.7-2.4,2.4-2.8,2.8-3.3 (mm)
- Alumina Ceramic
- White
- Ceramic Balls
Product Description
Duralox 92W Micro Beads
92% Purity High Alumina Ceramic
Duralox is a registred brand name of Jyoti's specially developed Proprietary composite. Duralox 92W spherical micro beads are produced from a proprietary formulation : A high alumina ceramic composite containing 92% alpha alumina crystals having a low percentage of silica in its body composition. Duralox 92W beads are tough & sapphire hard, measuring 9 on Moh's scale, dense in structure, abrasive in nature and resistant to abrasion wear, they can withstand high temperature and are chemically inert, non-porous, gas tight, non-toxic, non-magnetic, non-radioactive, free of voids
Duralox 92W micro beads have proven to be ideal for shot peening, de-burring and polishing of sheet metal blanks, cast moulded ferrous/non-ferrous components, precious metal ornaments etc.
Duralox 92W beads are found to be excellent as fillers to form wear resistant coating materials in epoxy resin based adhesive compounds. They form a tough, durable, abrasion resistant coating on complex surfaces such as scrapper blades, piping, chutes, hoppers, material passing passage etc. when placed with an epoxy matrix. These coating have a huge potential in ship building, chemical, food and beverage industries as they form tough, chemically inert, non-slippery, wear resistant flooring. In addition, they also provide outstanding service as light weight and abrasion resistant lining.
Due to their abrasive nature, Duralox 92W micro beads are generally not recommended for any bead milling dispersion applications.
| PHYSICAL PROPERTIES | |
| Colour | White |
| Surface Finish | Abrasive |
| Density | 3.70 0.05 g/cm3 |
| Bulk Density | 2.20 0.05 kg/ltr |
| Porosity | Nil |
| Water absorption | Nil |
| Hardness on Moh's scale | 9+ |
| Hardness on Vicker's scale (Hv5) | 1300 |
| Compressive Strength (20) | 2,000 Mpa |
| Crushing strength ( 2.0mm bead) | 90-100 kgf |
| Bead Sphericity 90% | 0.95 |
| Maximum use of Temperature (No Load Condition) | > 1400 (2550 ) |
| Co-efficient of Thermal Expansion(25 to 1000) | 7.6 x 106/ |
| CHEMICAL PROPERTIES | |
| Al2O3 | 92.3% |
| SiO2 | 2.55% |
| MgO | 2.45% |
| CaO | 2.10% |
| Others | 0.6% |
